Description:
The 4″ AccuCure Focused Wide Beam LightBar with built-in focused wide beam lens and active heat sink. With an aperture of 100mm x 20mm, the linear pattern air cooled LED optical head features continuous or pulse mode of operation. This LightBar is intended for UV curing in manufacturing and inspection line facilities with minimal installation requirements.
Narrow output spectrum is one of the primary benefits of LED curing systems over other technologies. Whereas other systems produce a variety of UV emission peaks and IR outputs that do not cure the product and may actually harm the substrate, LEDs provide a much more energy efficient, targeted cure. Additionally, the upfront cost of LEDs is offset by much lower operating energy and maintenance costs, with LED curing solutions lasting tens of thousands of hours compared with the mere hundreds of hours of operation of a mercury system. The AccuCure 4″ LightBar is available in a variety of UV / VIS wavelengths, with intensity starting at 5W/cm² for UV-A systems. Custom designed systems are available with no MOQs.
Available Wavelengths:
265nm, 285nm, 310nm, 365nm, 385nm, 395nm, 405nm, 420nm, 435nm, 445nm, 455nm, 470nm, 505nm, and additional wavelengths including UV-B & UV-C.
Physical Size (H x W x D):
100mm X 100mm X 80mm
Beam Pattern:
Linear
Aperture:
100mm x 20mm
Cooling:
Forced Air, Built-in Fan
Compatible Controllers:
